New Teardrop Style Uprights In Stock - North Carolina
Husky teardrop style uprights feature welded bracing and welded footplates. Mecalux teardrop style uprights have bolt on bracing and footplates.
Pallet Rack World. | Warehouse Rack | Pallet Racking | Wire Decks | Teardrop Style Pallet Rack | Teardrop Beams | Teardrop Uprights
Pallet Rack World is now stocking Interlake Mecalux and Husky Rack & Wire pallet rack uprights and beams. We are also pleased to announce that we are stocking Nashville Wire decking for the racks.
Available are best selling 12' high x 42'' deep teardrop uprights. These Interlake teardrop uprights feature a heavy duty 3'' x 3'' post. Also available are 8' and 9' long teardrop style beams. Complete your pallet rack system with wire mesh decking. 42'' deep x 46'' wide for the 8' beams and 42'' deep x 52'' wide for the 9' long beams.
If you have any question concerning deliveries, pick-ups or prices, please don't hesitate to contact us. Our friendly customer service staff will help find the best solutions for you.
New Teardrop Style Beams In Stock - Liberty, NC
Interlake teardrop style beams have a standard 1-5/8'' step. The teardrop style beams are available in 8' long for 40'' wide pallets and 9' long for 48'' wide pallets. Color Orange
New Wire Mesh Decking In Stock - Liberty, NC
Open grid wire mesh decking is used at most warehouses, distribution centers and manufacturing plants as a safety measure on selective pallet rack to prevent pallets from falling through the rack structure. Wire Decking complies with state and local Fire codes, providing an open deck so the heat can reach the sprinklers and allows water to extinguish the fire.
Phone: 336-253-8766 Email: sales@palletrackworld.com
Find us on
Facebook
Our Websites
Sitemap
Call to Order:
Email to Order:
336-253-8766
How to Order
Salesmen Covering the Following Areas: South Carolina | Columbia, SC | Charleston, SC | Aiken, SC | Florence, SC | Sumter, SC | Greenville, SC | Spartanburg, SC | Greer, SC | Fountain Inn, SC | Rock Hill, SC | Fort Mill, SC | North Carolina | Rocky Mount, NC | Greenville, NC | Winston Salem, NC | Asheville, NC | Hickory, NC | Statesville, NC | Newton, NC | Conover, NC | Charlotte, NC | Gastonia, NC | Monroe, NC | Sanford, NC | High Point, NC | Mebane, NC | Asheboro, NC | Salisbury, NC | Lexington, NC | Greensboro, NC | Kernersville, NC | Colfax, NC | Raleigh, NC | Durham, NC | RTP, NC | Clayon, NC | Danville, VA | Martinsville, VA | Burlington, NC | Graham, NC | Reidsville, NC | Eden, NC | Colfax, NC | Southern Pines, NC | Thomasville, NC | Roxboro, NC | Mathews, NC | Mint Hill, NC | Indian Trail, NC | Pineville, NC | Concord, NC
For a complete list of all pallet rack and wire decks, visit pallet rack world. Choose by type of rack, location of rack in stock or by manufacturer of pallet rack.
Carolina Material Handling Inc. ® 2209 Patterson Ct., Greensboro, NC 27407
The teardrop pattern is an industry standard and universal to most teardrop rack brands. So if you have existing teardrop style uprights and need to add some beams, they will work. Or if you have existing teardrop beams and need a few 12' high 42'' deep teardrop uprights, come by and pick some up.
Standard colors are green and blue uprights with orange beams from our Liberty, NC location just south of Greensboro, NC. The wire decks are powder coated in a gray finish.
For more sizes,colors, capacities and shipping locations, visit www.palletrackworld.com
Full Line - Racking Products
Territories Covered in NC, SC - Interlake Teardrop Style Pallet Racking and Wire Decks from Greensboro, NC
- Greensboro, NC
- Charlotte, NC
- Kernersville, NC
- Colfax, NC
- Monroe, NC
- Mathews, NC
- Fort Mill, SC
- Rock Hill, SC
- Concord, NC
- High Point, NC
- Burlington, NC
- Raleigh, NC
- Winston Salem, NC
- Hickory, NC
- Cary, NC
Size Post Capacity Color
8' High x 36'' Deep 3'' x 1-5/8'' Posts 18,160lbs Capacity Green
8' High x 42'' Deep 3'' x 1-5/8'' Posts 18,160lbs Capacity Green
8' High x 48'' Deep 3'' x 1-5/8'' Posts 18,160lbs Capacity Green
10' High x 48'' Deep 3'' x 1-5/8'' Posts 18,160lbs Capacity Green
12' High x 42'' Deep 3'' x 1-5/8'' Posts 18,160lbs Capacity Green
12' High x 48'' Deep 3'' x 1-5/8'' Posts 18,160lbs Capacity Green
12' High x 42'' Deep 3'' x 3'' Posts 25,390lbs Capacity Green
16' High x 42'' Deep 3'' x 3'' Posts 25,390lbs Capacity Green
16' High x 48'' Deep 3'' x 3'' Posts 25,390lbs Capacity Green
Mecalux Teardrop Style Uprights
Size Post Capacity Color
8' High x 42'' Deep 3'' x 2.56'' Posts 16,716lbs Capacity Blue
12' High x 42'' Deep 3'' x 2.56'' Posts 16,716lbs Capacity Blue
12' High x 48'' Deep 3'' x 2.56'' Posts 16,716lbs Capacity Blue
16' High x 42'' Deep 3'' x 2.7'' Posts 20,867lbs Capacity Blue
Husky Rack & Wire Teardrop Style Uprights
Part Number
IU18360096
IU18420096
IU18480096
IU18480120
IU18420144
IU18480144
IU24420144
IU24420192
IU24480192
Part Number
TU42-96
TU42-144
TU48-144
TU42-192
Size Capacity Color
4' Long x 2.7'' Face Step Beam 5,610lbs Orange
8' Long x 4'' Face Step Beam 5,370lbs Orange
9' Long x 4.5'' Face Step Beam 5,060lbs Orange
9' Long x 5'' Face Step Beam 6,150lbs Orange
10' Long x 5'' Face Step Beam 5,360lbs Orange
12' Long x 6.5'' Face Step Beam 7,110lbs Orange
Part Number
TB48-2.7
TB96-4
IBX43108
TB108-5
IBX48120
UTB144-6.5
Mecalux & Husky Teardrop Style Beams
Size
24'' Deep x 46'' Wide
36'' Deep x 46'' Wide
36'' Deep x 46'' Wide
36'' Deep x 52'' Wide
36'' Deep x 52'' Wide
42'' Deep x 46'' Wide
42'' Deep x 46'' Wide
42'' Deep x 46'' Wide
42'' Deep x 52'' Wide
42'' Deep x 52'' Wide
42'' Deep x 58'' Wide
44'' Deep x 46'' Wide
48'' Deep x 46'' Wide
48'' Deep x 46'' Wide
48'' Deep x 52'' Wide
48'' Deep x 58'' Wide
Part Number
D2446AA3B2
ND3646
D3646AA3B1
ND3652
D3652AA3B1
ND4246
D4246AA3A1
D4246EA3A2
ND4252
D4252AA3A1
D4258AA3A1
D4446AA3A1
D4846AA3C1
ND4846
D4852BA3A1
D4858BA3A1
Description
Nashville Deck, Flared
WWMH Deck, Standard
Nashville Deck, Standard
WWMH Deck, Standard
Nashville Deck, Standard
WWMH Deck, Standard
Nashville Deck, Standard
Nashville Deck, Flared
WWMH Deck, Standard
Nashville Deck, Standard
Nashville Deck, Standard
Nashville Deck, Standard
Nashville Deck, Standard
WWMH Deck, Standard
Nashville Deck, Standard
Nashville Deck, Standard
Capacity
2,500lbs
2,500lbs
2,700lbs
2,500lbs
2,700lbs
2,500lbs
2,700lbs
2,500lbs
2,500lbs
2,700lbs
2,750lbs
2,550lbs
2,500lbs
2,500lbs
2,500lbs
2,500lbs
Weight
11lbs
16lbs
16lbs
17lbs
17lbs
20lbs
20lbs
25lbs
22lbs
22lbs
23lbs
21lbs
25lbs
25lbs
27lbs
29lbs
